    High Power Industrial Solar Charge Controller Excellent Battery Storage Capability

    Ask Lasest Price
    Brand Name : Yo Power Electrical
    Model Number : YQPV-HP series
    Certification : CE, ROHS, FCC
    Price : Negotiable
    Payment Terms : L/C, D/A, Western Union, T/T, MoneyGram, Paypal
    Supply Ability : 500 units/Month
    Delivery Time : Within 3 days for 1~5pcs
    • Product Details
    • Company Profile

    High Power Industrial Solar Charge Controller Excellent Battery Storage Capability

    Yo Power Intelligent 20KW 50KW 100KW 240KW High Power Solar Charge Controller

    The 20KW 50KW 100KW 240KW High Power Solar Charge Controller is designed for off grid solar power system according to the latest technology development and represents the latest photovoltaic technology level. It suitable for almost off grid solar power system which usually install in any area where people doesn't have grid power or simply want to be independent from grid power and other fossil energy sources. Please checking features of our high power solar charge controller as following


    1. Features

    • Infineon IGBT power moduel
    • ABB/Schneider Control
    • PWM regulator technology with three-charging stages protect battery from over charging
    • Advanced battery activation technology improve the storage capability of battery and extend battery service life 30% at least compare to other solar controller
    • Users can adjust working parameters according to different type battery
    • Users can parallet connect lots to a system
    • 3'' LCD screen and LED indicators shows charging information
    • New SOC technology shows the generation power of daily, monthly and total
    • RTC function shows the real time and inner side temperature
    • The deep protection to avoid destroying battery when the power switch (IGBT) is down (optional function)
    • 3 years warranty at least

    If you have a solar power system, please tell me the rated voltage of battery bank system and max. charging current or total power of solar panels, we will recommend right model for you, the following is the parameters of some model of our high power solar charge controller, except them, we also provide other models, we also provide OEM/ODM service according to your demands, please feel free to contact us for details


    2. Parameters

    Rated system voltage240V360V384V420V480V540V600V
    Max. input voltage480V720V768V840V960V1000V1000V
    Rated charging current200A~400A, optional
    Stand-by consumption<0.5W
    Equalize charging voltage (absorption)288V432V460.8V504V576V648V720V
    Equalize charging time (default setting)120 minutes
    Float charging voltage276V414V441.6V483V552V621V690V
    Over voltage disconnect320V480V512V560V640V720V800V
    Over voltage reconnect300V450V480V525V600V670V750V
    Display3''LCD+LED
    Display laguageEnglish
    Indicator lightError indicator/Charging indicator
    Terminal typeTC series terminal
    Humidity0~98%, non-condensing
    Storage temperature-25℃~55℃
    Elevation≦4000M, please reduce the power if the elevation high than 4000M
    Protection levelIP32
    Noise<30dBA
    Dimension900*520*500mm
    N.WAbout 75KG
    Packing size540*560*1040mm
    G.WAbout 80KG
    Packing informationStandard exporting wooden case with pearl sponge
    Warranty3 years at least

    Remark: The parameters in red color are adjustable. Users can set them according to different battery demands


    3. Application


    These high power solar charge controller are designed for big power off grid solar system, according to different rated voltage and charging current, it suitable to different power solar system. If you have a solar power system but don't know which model is suitable, please tell us details about your solar system, then we recommend right model for you. Also we can recommend the right connection diagram of solar panels to get best charging efficiency.


    With the PWM regulator technology, the high power charge controller can protect battery from over charging, improve the storage capability of battery and extend the battery serive life time.
